1/3" 1.05mm 10Megapixel S mount M12 202degree Fisheye Lens for IMX172 IMX214, Drone UAV 360VR lens

Name: 13quot 105mm 10Megapixel S mount M12 202degree Fisheye Lens for IMX172 IMX214 Drone UAV 360VR lens
Brand: CCOM LENS
Price: 1 USD

Buy cheap 1/3" 1.05mm 10Megapixel S mount M12 202degree Fisheye Lens for IMX172 IMX214, Drone UAV 360VR lens product

Place of Origin : China

Model Number : 130105MP 130105MPF

Packaging Details : Standard

Delivery Time : 2-7 work days

Supply Ability : Samples available

Payment Terms : T/T, Western Union, Moneygram, Paypal

Brand Name : CCOM LENS

MOQ : 100pcs

Board Lens : M12 Mount Fisheye Lens

Resolution : 10MP

FOV : 202degree

Materials : Metal + Glass

Contact Now

High Definition Fisheye Lens

● High resolution

● Various application meet your requirements

● Compact design with cost-effective performance

● Custom design

● Super wide-angle with FOV up to 202° for panoramic surveillance
● Sharp image quality for multi-mega pixels cameras
● Suitable for various image frame
● IR cut option

1/3" 1.05mm 10Megapixel S mount M12*0.5 Mount 202degree IR Fisheye Lens, 1.05mm fisheye lens for IMX172/IMX214/OV10823, suitable for 360 VR Camera, Drone UAV lens, able to match 10MP sensors

MODEL 130105MP
IMAGE FORMAT 1/3" / Φ3.46mm(image circle)
FOCAL LENGTH(mm) 1.05
F.O.V. 202°(D)*202°(H)*202°(V)
RESOLUTION 10MP
F-THETA DISTORTION <-7.71%
APERTURE F2.4
MOUNT(mm) M12x0.5
IRIS Fixed
M.O.D.(mm) 0.1
B.F.L.(mm) 3.2
T.T.L.(mm) 24.5mm
R.I. >70%
Max. CRA 5.2°
DIMENSION(mm) Φ26x21.9
LENS COMPOMEMT 10-7

Tips:
- ***MP: without IR-Cut filter
- ***MPF: with IR-Cut filter
- 650nm/850nm/940nm IR filter optional

- This 1.05mm fisheye lens can be used on 1/2.6" sensors: http://www.megapixellenses.com/sale-8078125-1-2-6-1-08mm-10megapixel-m12x0-5-mount-200degrees-fisheye-lens-for-ccd-cmos.html

- For more fisheye lenses, please feel free to contact us at sales01@megapixellenses.com; cctv.lens@ccom-tech.com

2pcs 130105MP fisheye lenses back to back on IMX214:

1/3" 1.05mm 10Megapixel S mount M12 202degree Fisheye Lens for IMX172 IMX214, Drone UAV 360VR lens

Effect on IMX172:

1/3" 1.05mm 10Megapixel S mount M12 202degree Fisheye Lens for IMX172 IMX214, Drone UAV 360VR lens
